Lenovo Fibocom L860-GL Genuine 4G LTE CAT16 1Gbps WWAN M.2 Card (5W11H85373)
Regular price
$85.00
Lenovo Fibocom L860-GL Genuine 4G LTE CAT16 1Gbps WWAN M.2 Card (5W11H85373)
Regular price
$85.00
Lenovo
Lenovo Fibocom L860-GL Genuine 4G LTE CAT16 1Gbps WWAN M.2 Card (5W11H85373)
Genuine Fibocom L860-GL-16 4G LTE WWAN M.2 Card (5W11H85373)
All cards fully unlocked, local stock with 100% Australian-compliance, genuine and original, with quick shipping!
Don't risk imitations or slow shipping from unknown suppliers.
FRU PN: 5W11H85373
EC: 5443508
MPN: 8SSW11E39842J1BY2AS02Z5
FCC ID: ZMOL860GL16G
IC: 21374-L860GL16
NOTE: Item is tested working and OK, IMEI may differ from picture. Please check this will fit your machine. Buyer assumes all responsibility for checking compatibility with laptop before purchasing. Machine should also have 4x WWAN connectors, and SIM-card tray.
Suitable models (guide only, may also include others not listed):
- ThinkPad P14S Gen 3 AMD (MT 21J5/21J6)
- ThinkPad P14S Gen 3 Intel (MT 21AK/21AL)
- ThinkPad T14 Gen 3 AMD (MT 21CF/21CG)
- ThinkPad T14 Gen 3 Intel (MT 21AH/21AJ)
Not suitable for your machine or not sure which one you need?
See our range of other WWAN cards or send us a message.
---
See our range of other WWAN cards or send us a message.
---
Manufacturer information:
ThinkPad Fibocom L860 CAT16 4G LTE WWAN Module is a wireless communication module with receive diversity. It helps provide data connectivity and network with PCIe Gen2 M.2 interface. With downlink speed up to 1Gbps and uplink speed up to 150 Mbps, the 4G LTE CAT16 WWAN module enhances the network reliability and availability of your ThinkPad, and provides a great cellular solution for travelers to sustain mobility while using PC devices.
Tech Specs
Supported Band
FDD-LTE:
B1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/28/29/30/32/66/71
TDD-LTE:
B34/38/39/40/41(HPUE)/421)/43/48
LAA Band 46 Receiver only
WCDMA/HSPA+:
B1/2/4/5/8
GNSS:GPS/BDS/GLONASS/Galileo
B42 disabled as of FCC certification now
Weight
6.2g
Hardware Requirements
M.2 Key-B
Brand
ThinkPad
Other Electrical Specifications
Antenna Connector: WWAN Antenna x 4, Support 4x4 MIMO
Protocol Stack
IPV4/IPV6 Firmware Update: PCIe
Other Operating Environment
Extended operating temperature: –20℃ to +65℃ Storage temperature: –40℃ to +85℃
Other Physical Specifications
Interface: M.2 Key-B
Agency Approvals
CE for EU, KCC for Korea, IFT for Mexico, NTC for Philippines, ICASA for South Africa, NCC for Taiwan
Maximum Operating Temperature 55℃
Minimum Operating Temperature -10℃
Maximum Relative Humidity (%) 95%
Minimum Relative Humidity (%) 5%
Voltage DC 3.135V to 4.4V, typical 3.3V
